3 Meter Straight Line Cutting Machine 1500W High Precision

Name: 3 Meter Straight Line Cutting Machine 1500W High Precision
Brand: Guelinmen
Price: 8800 USD

Quality 3 Meter Straight Line Cutting Machine 1500W High Precision wholesale

Certification : ISO9001:2015

Device Framework : Stable structure, high precision

Model Number : GLM-CM

Working stroke : 1220*2800*50mm

Payment Terms : T/T,L/C,FOB,CIF

Reduction System : Shimpo(Japan)

Table structure : Vacuum adsorption with 7 major partitioned countertops, multi-point adsorption/multi-slot design/uniform adsorption/instantaneous adsorption/instantaneous release

Price : 8800 Dollars per Set

Control System : Taiwan Baoyuan Control System

Supply Ability : 10 Sets per Month

Rack & Pinion : German Doctor's 2M High-Precision Grinding Helical Rack

Bed frame structure : High-precision heavy-duty side-mounted bed, processed by a large-scale CNC five-axis milling machining center

MOQ : 1 Set

Delivery Time : 10-15 work days

Servo Motor System : 1500WHigh-performance general aviation servo system with X, Y and Z axes, each with a power of 1500W

Linear guide and lead screw : MNW domestic brand ball screw, XZ axis 25 guide rail, Y axis 30 model guide rail

Brand Name : Guelinmen

Product Name : 3-meter straight-line cutting machine

Packaging Details : Carton, Wooden Frame

Location mode : 3+2 High-precision Automatic Positioning Cylinder Push-button One-key Positioning Device - One-time Startup Device

Place of Origin : Guangzhou China

Main Power : Air-cooled tool-changing spindle with a rotational speed of 24,000 rpm

Contact Now

3-meter Straight-line Cutting Machine

3-meter straight-line cutting machine
Equipment Parameter
Working stroke	1220280050mm
Device Framework	Stable structure, high precision
Main Power	Air-cooled tool-changing spindle with a rotational speed of 24,000 rpm
Servo Motor System	1500W High performance general aviation servo system with X, Y and Z axes, each with a power of 1500W
Control System	Taiwan Baoyuan Control System
Reduction System	Shimpo(Japan)
Rack & Pinion	German Doctor's 2M High-Precision Grinding Helical Rack
Linear guide and lead screw	MNW domestic brand ball screw, XZ axis 25 guide rail, Y axis 30 model guide rail
Location mode	3+2 High-precision Automatic Positioning Cylinder Push-button One-key Positioning Device - One-time Startup Device
Bed frame structure	High-precision heavy-duty side-mounted bed, processed by a large-scale CNC five-axis milling machining center
Table structure	Vacuum adsorption with 7 major partitioned countertops, multi-point adsorption / multi-slot design / uniform adsorption / instantaneous adsorption / instantaneous release
Important electrical components	French Schneider relays are used alternately; Delixi
Pneumatic component	AIRTAC(TW)
Inverter	Zhongda brand 11KW inverter + braking resistor
Power cable	High-flexibility high-shielded cable, double-ply cable with protective sheaths, anti-interference and anti-damage capability
Loading materials and pushing materials	With auxiliary feeding rollers, one-time feeding, automatic pushing of materials and a secondary dust removal device
Cooling System	7.5KW water circulation cooling
Safety System	Over-speed protection / emergency stop protection / limit switch / air pressure alarm / safety guard / electrical protection, etc.
Vacuum system	UPVC vacuum pipeline + vacuum steel wire hose
Vacuum cleaning system	Floating vacuum cleaner
Connection piece	The transmission components are fixed with 12.9-grade high-strength screws, and the sheet metal is fixed with screws.
Accuracy guarantee	Each axis is rigidly fixed and positioning pins are installed on the precision parts.
Connection piece	Five-sided horizontal boring machine for fine processing
Power supply	380V
Quality Control	12-hour high-speed test of the machine

3 Meter Straight Line Cutting Machine 1500W High Precision

FAQ

Q1: Are aluminum honeycomb panels fire-resistant?

A: Yes, our fire-rated aluminum honeycomb panels achieve A1 grade non-combustible fire rating (EN 13501-1), meeting the highest safety standards for public and commercial buildings.

Q2:How to clean and maintain it in daily life?

A:Wipe with clean water and neutral detergent; Prohibit the use of strong acids, strong alkalis, and steel wire ball polishing; Outdoor rainwater self-cleaning, fluorocarbon surface dust is easy to wash away.

Q3: What is the packaging of the goods?

A:We apply a protective film to the product surface, then wrap it with foam, and finally place it in a wooden frame.

Q4: What is your payment term?

A: We accept the payment terms: T/T, L/C, FOB, CIF.

Q5: What are the transportation methods?

A: Ocean Shipping and railway transportation. Feel free to select the packaging and shipping options that best meet your specific requirements, ensuring a secure and efficient delivery of our aluminum plates.

Q6: Can I get a sample?

A: Yes, we can provide a free standard-size sample and the color board, but the delivery cost should be paid by you. For customized or large-size samples, you should bear both the sample cost and delivery cost

Q7: How long does it take for an order to be shipped?

A: It will take approximately 10-15 days.
